N Range - Nitrogen Generator
The PSA (Pressure Swing Adsorption) nitrogen generator can produce nitrogen with a purity of 99% to 99.99%.
| Model | N500 | N1000 |
|---|---|---|
| General Parameters | ||
| Dimensions L×W×H (mm) | 2,500×2,300×2,650 | 4,200×2,300×2,650 |
| Weight* (kg) | 8,000 | 14,000 |
| Air Outlet(in) | G2 | G3 |
| Performance Parameters | ||
| Volumetric Flow Rate | ||
| @ 99% Purity (m³/h) | 500 | 1,000 |
| @ 99.9% Purity (m³/h) | 380 | 760 |
| @ 99.99% Purity (m³/h) | 250 | 500 |
| Inlet Pressure (bar(e)) | 7～10 | 7～10 |
| Outlet Pressure (bar(e)) | 8.5 | 8.5 |
1. Unit perfomance measured according to ISO1217,Ed3,Annex C
2. *Container frame inclusive
Features
· Supports 99% / 99.9% / 99.99% nitrogen purity options, with dynamic output adjustment based on purity level
· Integrated container frame with wind and rain protection, ensuring stable long-term operation in harsh outdoor environments
· N500/N1000 models cover nitrogen demands from small and medium to large-scale applications
· Performance tested in strict accordance with ISO1217 international standards to ensure data reliability
Advantages
· The N1000 model delivers up to 1000 m³/h at 99% purity, meeting large-scale gas demand in electronics manufacturing, chemical industries, and more
· Compact containerized design enables plug-and-play installation, reducing setup costs
· Wide inlet pressure range of 7–10 bar(e) with a constant 8.5 bar(e) outlet pressure ensures downstream equipment compatibility
· Fully enclosed protective structure reduces environmental corrosion, extending equipment lifespan and lowering maintenance frequency
